AWS SageMaker: Custom Model Deployment with NeuroLink

By the end of this guide, you’ll have custom models deployed on AWS SageMaker and accessible through NeuroLink’s unified TypeScript API – with the same generate() and stream() interface you use with every other provider.

You will configure SageMaker endpoints, connect them to NeuroLink, handle credential management, and set up health checks and error handling. SageMaker gives you full control over compute, scaling, and data flow; NeuroLink gives you a clean TypeScript SDK on top.

Configuration Architecture

SageMaker is the most configuration-intensive provider in NeuroLink, reflecting the complexity of AWS infrastructure. The configuration is split into two parts: AWS-level config and model-level config.

AWS Configuration

The SageMakerConfig type handles AWS authentication and connectivity:

Parameter	Environment Variable	Default	Description
region	SAGEMAKER_REGION or AWS_REGION	us-east-1	AWS region for the SageMaker endpoint
accessKeyId	AWS_ACCESS_KEY_ID	Required	AWS access key
secretAccessKey	AWS_SECRET_ACCESS_KEY	Required	AWS secret key
sessionToken	AWS_SESSION_TOKEN	Optional	For temporary credentials (STS)
timeout	SAGEMAKER_TIMEOUT	30000 (30s)	Request timeout in milliseconds
maxRetries	SAGEMAKER_MAX_RETRIES	3	Maximum retry attempts
endpoint	SAGEMAKER_ENDPOINT	Optional	Custom SageMaker endpoint URL

Region resolution follows a priority chain: explicit parameter > SAGEMAKER_REGION env var > AWS_REGION env var > us-east-1 default.

Model Configuration

The SageMakerModelConfig type handles model-specific settings:

Parameter	Environment Variable	Description
endpointName	SAGEMAKER_DEFAULT_ENDPOINT or SAGEMAKER_ENDPOINT_NAME	Name of the SageMaker endpoint
model	SAGEMAKER_MODEL	Model identifier for the SageMaker endpoint
modelType	SAGEMAKER_MODEL_TYPE	One of: llama, mistral, claude, huggingface, jumpstart, custom
contentType	–	Default: application/json
inputFormat	–	One of: huggingface, jumpstart, custom
outputFormat	–	One of: huggingface, jumpstart, custom
maxTokens	–	Maximum tokens to generate
temperature	–	Sampling temperature
topP	–	Top-p (nucleus) sampling
stopSequences	–	Stop sequences for generation

Both configurations are validated via Zod schemas (SageMakerConfigSchema, SageMakerModelConfigSchema), providing clear error messages when configuration is missing or invalid.

Note: The current NeuroLink SageMaker provider requires AWS access-key credentials: AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY, with an optional AWS_SESSION_TOKEN, or equivalent per-call credentials. It does not currently use the AWS SDK’s default IAM-role credential chain.

Quick Setup

Environment Variables

export AWS_ACCESS_KEY_ID=AKIA...
export AWS_SECRET_ACCESS_KEY=wJal...
export AWS_REGION=us-east-1

# SageMaker-specific
export SAGEMAKER_DEFAULT_ENDPOINT=my-llama-endpoint
export SAGEMAKER_MODEL=custom-llama-3
export SAGEMAKER_MODEL_TYPE=llama

Basic Generation

import { NeuroLink } from '@juspay/neurolink';

const neurolink = new NeuroLink();

const result = await neurolink.generate({
  input: { text: "Summarize this quarterly report" },
  provider: "sagemaker",
});

console.log(result?.content);

That is it. NeuroLink loads AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY (plus AWS_SESSION_TOKEN when present) from environment variables, validates them against the Zod schema, connects to the specified SageMaker endpoint, and formats the request according to the configured modelType. You can instead supply the same access-key fields as per-call credentials.

For programmatic access to a provider instance – which the diagnostics below need – use the exported AIProviderFactory, the same factory NeuroLink’s provider registry uses internally to build the SageMaker provider:

import { AIProviderFactory } from '@juspay/neurolink';

const provider = await AIProviderFactory.createProvider(
  "sagemaker",
  "custom-llama-3",   // modelName
  true,               // enableMCP
  undefined,          // sdk
  "us-west-2",        // region
);

AmazonSageMakerProvider itself is an internal class, not one of @juspay/neurolink’s public exports, so this path has no explicit endpointName argument – set SAGEMAKER_DEFAULT_ENDPOINT or SAGEMAKER_ENDPOINT_NAME instead.

Supported Model Types

SageMaker can serve any model, but different models expect different request/response formats. NeuroLink’s modelType configuration tells the provider how to format requests for your specific model:

Model Type	Input Format	Best For	Example
llama	Llama chat template	Meta Llama models deployed via SageMaker	Llama 3.1 8B, 70B
mistral	Mistral chat format	Mistral models on SageMaker	Mistral 7B, Mixtral
claude	Anthropic message format	Claude models on SageMaker	Claude 3 via Bedrock-SageMaker
huggingface	HuggingFace Inference format	Any HuggingFace model	Custom fine-tuned models
jumpstart	AWS JumpStart format	Pre-built JumpStart models	Foundation models from JumpStart
custom	Your own format	Custom model servers	Your own model format

The custom Model Type

The custom model type is the most flexible option. It lets you define your own input and output format parsers, which is essential when deploying models with non-standard inference APIs:

// For a custom model type, define your own input/output handling
const result = await neurolink.generate({
  input: { text: "Process this request" },
  provider: "sagemaker",
  model: "my-custom-model",
});

When using custom, you can also set inputFormat and outputFormat to custom in the model configuration, giving you full control over request serialization and response parsing.

Testing and Health Checks

SageMaker deployments involve multiple moving parts (credentials, endpoints, networking, model readiness), so NeuroLink provides comprehensive testing utilities.

Configuration Check

const provider = await AIProviderFactory.createProvider("sagemaker", "my-model");

// Quick configuration overview
const info = provider.getSageMakerInfo();
console.log(info);
// {
//   endpointName: "my-endpoint",
//   modelType: "llama",
//   region: "us-east-1",
//   configured: true
// }

The getSageMakerInfo() method returns a summary of the current configuration without making any API calls. Use this to verify your configuration is correct before attempting a connection.

Connection Testing

// Test actual connectivity
const conn = await provider.testConnection();
if (!conn.connected) {
  console.error("Connection failed:", conn.error);
  // Possible errors (configuration-only checks, no API call is made):
  // "AWS credentials not configured"
  // "SageMaker endpoint not configured"
}

The testConnection() method checks that credentials and an endpoint name are present – it does not call AWS. For deeper testing, testConnectivity() makes a lightweight inference call to confirm the endpoint actually responds (errors like “endpoint not found” or an endpoint that isn’t InService surface from that call, or from generate(), not from testConnection()).

Model Capabilities

const capabilities = provider.getModelCapabilities();
console.log(capabilities);
// {
//   ...modelInfo,          // modelId, endpointName, modelType, region, ...
//   capabilities: {
//     streaming: true,
//     toolCalling: true,
//     structuredOutput: true,
//     batchInference: true,
//     supportedResponseFormats: ["text", "json_object", "json_schema"],
//     maxBatchSize: 100,
//     ...
//   }
// }

Tip: Run testConnection() during deployment for a fast preflight check of credentials and endpoint configuration. If deployment must also verify that the endpoint responds, run testConnectivity(), which sends a lightweight inference request.

Configuration Summary for Debugging

When things go wrong, the provider’s public getSageMakerInfo() method gives you a concise, non-secret view of the active endpoint configuration:

const info = provider.getSageMakerInfo();
console.log(JSON.stringify(info, null, 2));

It reports the endpoint name, model type, region, and whether access-key credentials are configured. It does not expose the credential values themselves, so it is suitable for deployment diagnostics.

Endpoint Types

SageMaker supports several endpoint types, each suited to different workloads. NeuroLink’s type system includes types for all of them:

Real-Time Inference

The standard deployment mode. Your model is loaded into memory on a dedicated instance and serves requests synchronously with low latency.

// Real-time endpoints are the default
const result = await neurolink.generate({
  input: { text: "Classify this document" },
  provider: "sagemaker",
});

Batch Transform

For processing large datasets asynchronously. Input data is read from S3, processed by the model, and output is written back to S3. This is configured through the BatchInferenceConfig type:

// Batch inference configuration (via SageMaker API, not NeuroLink directly)
// BatchInferenceConfig type includes:
// - inputS3Uri: S3 path to input data
// - outputS3Uri: S3 path for output
// - instanceType: e.g., "ml.m5.xlarge"
// - instanceCount: number of instances
// - maxPayloadInMB: maximum request size (optional)

Multi-Model Endpoints

Deploy multiple models behind a single endpoint, reducing infrastructure costs by sharing compute resources. The SageMakerEndpointInfo type tracks endpoint metadata including status, model variants, and creation timestamps.

Error Handling

SageMaker has a dedicated error system with a custom SageMakerError class and typed error codes:

Error Code	Description	Common Cause
VALIDATION_ERROR	Invalid configuration	Missing endpoint name, bad model type
CREDENTIALS_ERROR	AWS authentication failure	Expired keys, wrong region, missing permissions
ENDPOINT_NOT_FOUND	Endpoint does not exist	Typo in endpoint name, endpoint deleted
THROTTLING_ERROR	Rate limit exceeded	Too many requests for endpoint capacity
MODEL_ERROR	Model inference failure	Invalid input format, model OOM
NETWORK_ERROR	Connection issues	VPC configuration, security groups
SERVICE_UNAVAILABLE	SageMaker service issue	AWS service disruption
INTERNAL_ERROR	Internal error	Unexpected failures

try {
  const result = await neurolink.generate({
    input: { text: "Process this" },
    provider: "sagemaker",
  });
} catch (error) {
  if (error.code === "CREDENTIALS_ERROR") {
    console.error("Check your AWS credentials and IAM permissions");
  } else if (error.code === "ENDPOINT_NOT_FOUND") {
    console.error("SageMaker endpoint does not exist. Check the endpoint name and region.");
  } else if (error.code === "THROTTLING_ERROR") {
    console.error("Endpoint is throttled. Consider scaling up the instance count.");
  } else {
    console.error("SageMaker error:", error.message);
  }
}

The handleProviderError() method wraps all errors with appropriate context, and handleSageMakerError() provides consistent formatting across the provider.

Warning: SageMaker errors related to credentials often indicate IAM permission issues, not just wrong keys. Make sure your IAM role has sagemaker:InvokeEndpoint permission for the specific endpoint ARN.

Architecture

Here is the complete architecture of NeuroLink’s SageMaker integration:

flowchart TB
    A[Your App] --> B[NeuroLink SDK]
    B --> C[AmazonSageMakerProvider]
    C --> D[SageMakerLanguageModel]
    D --> E[AWS SageMaker API]

    subgraph "Configuration"
        F["getSageMakerConfig()<br/>AWS credentials + region"]
        G["getSageMakerModelConfig()<br/>Endpoint + model type"]
        H["Zod Validation<br/>SageMakerConfigSchema"]
    end

    subgraph "Endpoint Types"
        I["Real-time Inference"]
        J["Batch Transform"]
        K["Multi-Model Endpoint"]
    end

    E --> I
    E --> J
    E --> K

    subgraph "Model Types"
        L[Llama]
        M[Mistral]
        N[Claude]
        O[HuggingFace]
        P[JumpStart]
        Q[Custom]
    end

The key architectural distinction from other providers is the SageMakerLanguageModel layer. While most NeuroLink providers use off-the-shelf AI SDK packages (like @ai-sdk/openai), SageMaker uses a custom implementation that is structurally compatible with the AI SDK v6 LanguageModelV2 interface. It handles AWS authentication, endpoint invocation, and model-type-specific request/response formatting.

Credential Management

Static Credential Requirement

The AWS SDK normally supports instance and task roles through its default credential chain, but the current NeuroLink SageMaker integration does not use that chain. Its configuration validation requires a non-empty access key ID and secret access key, and its runtime client passes those credentials explicitly. Until that implementation changes, configure AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY (or pass equivalent per-call credentials) even when the workload itself runs on EC2, ECS, or Lambda.

Temporary Credentials (STS)

For cross-account access or time-limited sessions, use AWS STS temporary credentials:

export AWS_ACCESS_KEY_ID=ASIA...
export AWS_SECRET_ACCESS_KEY=temp_secret...
export AWS_SESSION_TOKEN=FwoGZXIvYXdz...

The sessionToken is automatically included in SageMaker API calls when present.

Credential Validation

NeuroLink performs minimal format validation on credentials – checking that they are present and roughly the right shape – but delegates detailed validation to the AWS SDK. This is a security best practice: NeuroLink never stores or logs full credentials, and format validation alone cannot determine if credentials are valid.

Region format validation uses the pattern /^[a-z0-9-]+$/, and checkSageMakerConfiguration() provides a comprehensive pre-flight check that validates all configuration aspects.

Production Best Practices

Auto-Scaling

Configure auto-scaling for your SageMaker endpoints to handle variable load. The ModelDeploymentConfig type includes auto-scaling parameters:

// Monitoring endpoint metrics
// EndpointMetrics type includes:
// - invocations (total request count)
// - averageLatency
// - errorRate
// - cpuUtilization
// - memoryUtilization
// - instanceCount

Cost Management

SageMaker pricing is instance-based, not per-token. The CostEstimate type breaks down costs into instance cost, request cost, and total processing hours. Monitor these metrics to right-size your instances.

Configuration from File

For complex deployments, use loadConfigurationFromFile() to load SageMaker configuration from a JSON or YAML file rather than relying solely on environment variables.

Key Recommendations

1. Scope access-key permissions narrowly to the required SageMaker endpoint while the provider requires explicit credentials
2. Configure auto-scaling for production endpoints to handle traffic spikes
3. Monitor with EndpointMetrics to detect latency degradation and error rate increases
4. Use session tokens for temporary access in CI/CD pipelines
5. Run testConnectivity() during deployment to verify the endpoint responds
6. Set appropriate timeouts – SAGEMAKER_TIMEOUT=30000 (30s) is the default; increase for large models

What’s Next

You now have SageMaker working through NeuroLink’s unified interface. From here:

• Hugging Face Integration: Discover open-source models on Hugging Face, then deploy them to SageMaker for production use
• LiteLLM Unified Routing: Route requests across multiple providers including SageMaker endpoints
• Provider Comparison Matrix: Compare SageMaker against other enterprise deployment options like Bedrock and Vertex

SageMaker gives you maximum control over your AI infrastructure. Combined with NeuroLink’s unified interface, you get full infrastructure control with the developer experience of a managed API.

---
