Grading the model: the scorer hierarchy and evaluation pipeline
Inside NeuroLink's evaluation system: the BaseScorer/BaseLLMScorer/BaseRuleScorer class hierarchy, the PipelineBuilder-driven EvaluationPipeline that runs scorers together, and how batching, factories, and observability hooks fit around it.
We designed NeuroLink’s scorer hierarchy because a single, monolithic evaluation function was difficult to test, extend, or debug. If a RAG pipeline’s FaithfulnessScorer were to start returning anomalous scores — say, after an upstream provider changed its output format — a monolithic function would give us no way to isolate that from the ToxicityScorer or the deterministic FormatScorer running in the same evaluation pass. A failure in one check could silently corrupt the entire result. We needed a system where every evaluation concern was a distinct, composable class, managed by a predictable pipeline.
This post dives deep into that architecture. It’s the next level of detail from our previous post on Model Evaluation and Scoring: RAGAS-Style Quality Assessment, which covered the what of our metrics. Here, we cover the how: the class hierarchy, the pipeline orchestrator, and the observability hooks that make our evaluation system robust and extensible.
The Scorer Class Hierarchy
At the root of the system is BaseScorer. This abstract class defines the universal contract for any scorer: a score method that takes an input and returns a result. It also provides foundational utilities that all scorers inherit, including input validation, score normalization, and a robust executeWithRetry mechanism for handling transient network failures.
From this base, the hierarchy splits into two distinct branches.
BaseLLMScoreris the parent for any evaluation that requires a provider call. It introduces the core abstractions for this pattern: an abstractgeneratePromptmethod to create the provider-specific prompt and an abstractparseResponsemethod to interpret the model’s output. It handles the mechanics of the actual API call through itscallLLMmethod.BaseRuleScoreris the parent for deterministic, offline evaluations. It operates without any external LLM calls. Instead, it manages a collection ofScorerRuleobjects and provides anevaluateRulemethod to execute them. It supports multiple modes for combining rule results, such as requiring all rules to pass (all), any rule to pass (any), or calculating a weighted score.
This division ensures a clean separation of concerns. A scorer either talks to an LLM or it does not. There is no ambiguity.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
// All scorers, regardless of type, share a common foundation.
export abstract class BaseScorer {
// The universal contract for all scorers
abstract score(input: ScorerInput): Promise<ScoreResult>;
// Built-in resilience for any scorer
protected async executeWithRetry<T>(
fn: () => Promise<T>,
...
): Promise<T>;
}
// For scorers that call a provider like OpenAI or Anthropic
export abstract class BaseLLMScorer extends BaseScorer {
abstract generatePrompt(input: ScorerInput): string;
abstract parseResponse(response: string, input: ScorerInput): Partial<ScoreResult>;
protected async callLLM(prompt: string): Promise<string>;
}
// For deterministic, offline checks
export abstract class BaseRuleScorer extends BaseScorer {
abstract getRules(): ScorerRule[];
abstract evaluateRule(rule: ScorerRule, input: ScorerInput): RuleResult;
}
The Scorer Implementations
The scorers/ directory contains the concrete implementations of this hierarchy. NeuroLink ships with over a dozen pre-built scorers, each targeting a specific quality dimension.
The LLM-based scorers, which extend BaseLLMScorer, include:
FaithfulnessScorer: Checks if the model’s answer is factually grounded in the provided context.HallucinationScorer: Detects statements that are not supported by the context.AnswerRelevancyScorer: Measures if the answer directly addresses the user’s question.ContextPrecisionScorer: Evaluates if the context provided to the LLM was relevant and concise.ToxicityScorer: Flags harmful, offensive, or biased language.SummarizationScorer: Assesses the quality of a summary against the original text.ToneConsistencyScorer: Checks if the response adheres to a specified tone.
The rule-based scorers, which extend BaseRuleScorer, handle deterministic checks:
FormatScorer: Validates that the output conforms to a required format (e.g., JSON, XML, Markdown).KeywordCoverageScorer: Ensures specific keywords are present in the output.LengthScorer: Checks if the output is within a given length range.
A special case is ContentSimilarityScorer, which extends BaseScorer directly. It uses algorithms like Jaccard and Levenshtein distance to measure similarity without an LLM call.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
// src/lib/evaluation/scorers/llm/answerRelevancyScorer.ts
export class AnswerRelevancyScorer extends BaseLLMScorer {
// Each LLM scorer implements a specific prompt generation strategy.
generatePrompt(input: ScorerInput): string {
const { query, response } = input;
if (!query || !response) {
throw new Error("Query and response are required for AnswerRelevancyScorer.");
}
// The prompt asks a separate evaluation model to grade the primary model's output.
return `
Given the question: "${query}"
And the answer: "${response}"
Please evaluate the relevancy of the answer to the question on a scale of 1 to 10.
A score of 1 means completely irrelevant.
A score of 10 means perfectly relevant.
Provide your reasoning in a JSON object with "score" and "reason" fields.
`;
}
// It also implements a corresponding response parser.
parseResponse(response: string, input: ScorerInput): Partial<ScoreResult> {
const json = this.extractJSON(response);
return {
score: json?.score,
reasoning: json?.reason,
};
}
}
Registration and Custom Builders
Scorers aren’t used via direct instantiation. Instead, they are managed by the ScorerRegistry. On startup, ScorerRegistry.registerBuiltInScorers() dynamically imports and registers all the standard scorers, making them available by ID.
For cases where a full class is overkill, we built ScorerBuilder. This fluent API lets you define a custom scorer programmatically. You can create simple rule-based scorers for checking patterns, keywords, or length on the fly. For more complex logic, createFunctionScorer wraps any function into a valid scorer object, and composeScorers can combine multiple scorers into a single, weighted evaluation.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
// Dynamically creating a rule-based scorer without a new class.
const jsonFormatScorer = ScorerBuilder.create('custom-json-check', 'JSON Format Check')
.description('Ensures the output is valid JSON')
.type('rule')
.customRule({
id: 'is-json',
description: 'Is Valid JSON',
type: 'custom',
params: {
evaluate: (input: ScorerInput) => {
try {
JSON.parse(input.response);
return { passed: true, score: 1 };
} catch {
return { passed: false, score: 0 };
}
},
},
})
.build();
The Evaluation Pipeline
Individual scorers are the building blocks. The EvaluationPipeline is the engine that runs them. It takes a set of scorers and an input, executes the scorers, and aggregates their results. This architecture is distinct from the main API request lifecycle described in From User Input to Provider API: The Five-Stage Message Flow; this is a dedicated, post-processing evaluation stage.
We use the PipelineBuilder to construct pipelines. It offers a fluent API for adding scorers, setting execution policies, and defining aggregation strategies. You can run scorers in parallel with parallel() for speed or in sequence with sequential() for dependent checks. You can also configure whether the pipeline should stopOnFailure() or continueOnFailure().
graph TD
subgraph Pipeline Execution
A[ScorerInput] --> B{EvaluationPipeline};
B -- dispatches to --> C1["FaithfulnessScorer - LLM"];
B -- dispatches to --> C2["FormatScorer - Rule"];
B -- dispatches to --> C3["..."];
end
subgraph Scoring
C1 -- calls provider --> D["External LLM Provider"];
D -- response --> C1;
C1 --> E1[ScoreResult];
C2 -- evaluates rules --> E2[ScoreResult];
C3 --> E3[ScoreResult];
end
subgraph Aggregation
E1 --> F{EvaluationAggregator};
E2 --> F;
E3 --> F;
F -- calculates stats --> G[Final EvaluationData];
end
The builder produces an EvaluationPipeline instance, ready to execute. For common use cases, we ship a set of PipelinePresets like safety, rag, quality, and codeGeneration, which provide pre-configured pipelines for turnkey evaluations.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
// Building a RAG quality pipeline using the fluent API
const ragPipeline = await PipelineBuilder.create('rag-quality-pipeline')
.description('Evaluates the quality of a RAG system response.')
.addScorer('faithfulness')
.addScorer('answer-relevancy')
.addScorer('context-precision')
.aggregateWith('weighted')
.withWeights({
'faithfulness': 0.5,
'answer-relevancy': 0.3,
'context-precision': 0.2,
})
.parallel()
.timeout(5000)
.buildAndInitialize();
// const results = await ragPipeline.execute(myScorerInput);
Batch Processing at Scale
Evaluating a single interaction is useful, but robust quality assessment requires running evaluations over large datasets. BatchStrategy, in pipeline/strategies/, is built for exactly this: it wraps an EvaluationPipeline and exposes an evaluate method that runs an array of ScorerInput through the pipeline with a configurable concurrency limit, continueOnError handling, and progress/result callbacks.
NeuroLink also ships a BatchEvaluator, but it batches a different, adjacent system: the single-call, RAGAS-style auto-evaluator (Evaluator) that grades one generate() result at a time, not the scorer EvaluationPipeline. It takes a config object (concurrency, maxRetries, retryDelay) and runs evaluateBatch over an array of { id, options, result } items. This is a core part of our internal quality control, as detailed in How We Test NeuroLink: 20 Continuous Test Suites and Counting.
1
2
3
4
5
6
7
8
9
10
// Running an EvaluationPipeline over a dataset with BatchStrategy
async function runBulkEvaluation(pipeline: EvaluationPipeline, dataset: ScorerInput[]) {
const batchStrategy = new BatchStrategy(pipeline, {
concurrency: 10, // Process 10 items in parallel
continueOnError: true, // Keep going if one item fails
});
const { summary } = await batchStrategy.evaluate(dataset);
console.log(`Batch evaluation complete: ${summary.passingRate}% passing`);
}
The Factory and Registry Bridge
The RAGAS-style Evaluator track has its own factory and registry — EvaluatorFactory and EvaluatorRegistry — following the same singleton-factory pattern we use for providers, as seen in our adapter catalog.
EvaluatorFactory.getInstance() resolves named configuration presets (default, strict, lenient, fast, premium, or a custom one registered with registerPreset) into a configured Evaluator, selecting the backing LLM via environment variables like NEUROLINK_RAGAS_EVALUATION_PROVIDER. EvaluatorRegistry.getInstance() is a separate singleton holding pluggable evaluation strategies (the built-in ragas strategy, plus any custom one you register) rather than pipeline presets. BatchEvaluator, covered above, is built on this same Evaluator, not on EvaluationPipeline.
The scorer/pipeline hierarchy has its own, simpler preset mechanism instead: getPreset(name) returns a PipelineConfig for safety, rag, quality, codeGeneration, and the other PipelinePresets, which you pass to new EvaluationPipeline(config) or build the same shape with PipelineBuilder.
1
2
3
4
5
6
7
8
9
10
// Getting a pre-configured evaluator for the current environment
async function getEvaluatorForEnvironment() {
const factory = EvaluatorFactory.getInstance();
// Resolves the 'strict' preset and configures its backing LLM
// based on environment variables.
const strictEvaluator = await factory.create('strict');
return strictEvaluator;
}
Observability and Reporting
A black-box evaluation pipeline is a blind spot. We built ObservabilityHooks to provide deep visibility into the evaluation process. It’s a typed event emitter that fires lifecycle events: pipeline:start, pipeline:end, scorer:start, and scorer:end.
You can subscribe to these events to log performance, trace execution, or collect metrics. We ship a MetricsCollector that does exactly this. The createMetricsCollectorHook adapter wires the collector to the pipeline’s events, automatically tracking per-scorer latency, success rates, and score distributions. For external systems, we also provide adapters like LangfuseAdapter to stream evaluation data to third-party observability platforms. Finally, ReportGenerator can consume the aggregated data to produce human-readable quality reports.
1
2
3
4
5
6
7
8
9
10
11
12
13
// Subscribing to lifecycle events for custom logging
const pipeline = await new PipelineBuilder().addScorer('toxicity').buildAndInitialize();
const hooks = new ObservabilityHooks();
hooks.on('scorer:start', ({ scorerName }) => console.log(`Scorer ${scorerName} started.`));
hooks.on('scorer:end', ({ scorerName, result }) => {
console.log(`Scorer ${scorerName} finished with score ${result.score}.`);
});
// The pipeline doesn't wire itself to a hooks instance automatically — emit
// lifecycle events yourself around the calls you want observed, e.g.:
// await hooks.emit('scorer:start', { scorerId, scorerName, timestamp: Date.now() });
const result = await pipeline.execute(myScorerInput);
Structured Error Handling
Reliable automation depends on predictable error handling. Every potential failure point in the evaluation pipeline, from input validation to provider timeouts, is mapped to a set of EvaluationErrorCodes. When a scorer or pipeline fails, it does so with a structured error, not just a generic exception. This allows consuming systems to build robust retry and alerting logic tailored to the specific failure mode.
1
2
3
4
5
6
7
8
9
10
11
try {
await pipeline.execute(input);
} catch (e) {
if (e.code === EvaluationErrorCodes.PROVIDER_ERROR) {
// Specific logic for when the evaluation model is down
console.error("Evaluation provider is unavailable. Retrying later.");
} else {
// General error handling
console.error("An unexpected evaluation error occurred:", e.message);
}
}
